DIMENSIONS (CONT)
14.97 [380]
14.98 [380]
14.25 [362]
14.26 [362]
12.53 [318]
12.54 [319]
11.05 [281]
9.70 [246]
4.34 [110] 4.33 [110]
4.53 [115]
13.51 [343]
12.01 [305]
2.28 [58]
2.13 [54]
1.23 [31]
18.96 [482] 20.16 [512]
6.65 [169]
10.68 [271]
47.00 [1194]
10.68 [271]
10.30 [262]
11.77 [299]
10.98 [279]
47.01 [1194]
2.53 [64]
2.19 [56]
Units: Inch (mm)
Flexible d'évacuation Ø0.625 (16) L=21 (538)
Fig. 5 - 24K, 30K, 36K
