ATTIX 145-01 / ATTIX 155-01
Separator cleaning and replacement (if
equipped)
1.
Separator
2.
Band
3.
Cover
4.
Screws
If there is only a dust deposit on the separator (1) allow the
dust to drop through the central hole.
The separator (1) should first be disassembled in order to be
perfectly cleaned:
■
Use the band (2) to remove the cover (3) together with
the filter.
■
Unscrew the two screws (4) and remove it from the
container.
Replace the part if it is excessively worn. Assemble the
components in the reverse order of disassembly.
Disposing of the vacuum cleaner
Dispose of the vacuum cleaner in compliance with the laws in
force.
Proper disposal (electric and electronic waste).
■
(Applicable in the European Union and in countries
providing a separate collection system)
The above symbol (Fig. 19), which is present on the product
or in its documentation, indicates that the product cannot be
disposed of together with other domestic waste at the end of
its life cycle.
To prevent damage to the environment or health caused by
improper waste disposal, please separate this product from
other waste and recycle it responsibly in order to support the
sustainable reutilisation of material resources.
This product can not be disposed of together with other
commercial waste.
GB
C366
Figure 17
[ NOTE ]
Figure 18
Wiring diagrams
Basic model
1.
Plug
2.
Vacuum cleaner
3.
Circuit breaker
Item
Part
Circuit breaker
Q1
Box for Q1
Model for vacuuming liquids
1.
Power input
2.
Transformer
3.
Liquid sensor
4.
Auto release
5.
Vacuum cleaner
6.
Circuit breaker
Item
Part
Circuit breaker
Q1
Handle for Q1
B1
Auto release
PR1
Pressure switch
F1-F2
Fuse holder
TR1
Transformer
10
Figure 19
Code
ATTIX
ATTIX
145-01
155-01
Z8 39915
Z8 39916
Z8 39932
Z8 39932
Figure 20
Code
ATTIX
ATTIX
145-01
155-01
Z8 39915
Z8 39916
Z8 39954
Z8 39954
Z8 391142
Z8 391142
Z8 40841
Z8 40841
Z8 39244
Z8 39244
Z8 391050
Z8 391050
03/2011
