CombiTemp™ TFRH/N
6.3 Mounting DFON display
ATTENTION
Damage of the front cover or ring
Do not use tools to tighten the front cover or screwing ring.
f
„
Remove the front cover.
f „
Remove the O-ring from the sealing groove.
f „
Connect the DFON display to FlexTop.
f „
FlexTop 2202: According to pin assignment.
„ „
FlexTop 2212/2222: With internal UnitCom cable.
„ „
Tighten the screwing ring by hand.
f
„
6.4 Connecting FlexProgrammer
Connection to FlexTop™ 2202
1
Connection to DFON display
1
10 / 54
Temperature measurement
RTD temperature sensor
2
2
Operating Instructions
1 Com 1
2 Com 2
Open housing by unscrewing the cover.
f
„
Connect the red clip to Com 1.
f
„
Connect the black clip to Com 2.
f „
1 Com 1
2 Com 2
Open housing by unscrewing the cover.
f
„
Connect the red clip to Com 1.
f
„
Connect the black clip to Com 2.
f
„
