5 - PASSAGE SEQUENCE (with ticket normal mode)

espas20 triggers a loop which detects the presence of a customer. At this point the

display and the light of the ticket request button illuminate:

- the driver must press the button (point D) to collect the ticket from the

special slot (point F)

The presence of a sensor on the ticket emission slot allows espas20 to open the barrier

only once the users have collected ticket.

In this way the driver cannot access the car park unless provided with a valid ticket.

espas20 maintains the barrier open until the user has successfully passed through it:

this takes place thanks to a safety loop located on the barrier arm.

At this point the barrier remains open until the customer has safely passed through it.

NOTE: If the driver take the ticket and release the presence loop, the barrier close

within 5 sec if the driver wont occupy the safety loop.

A number of cards can be programmed to execute special functions when presented

to the reader, even in absence of a vehicle on the loop. The available functions are for

changing the operating mode:

Normal mode (up to 4 cards can be registered)

Open mode (up to 4 cards can be registered)

Closed mode (up to 4 cards can be registered)

Loop mode (up to 4 cards can be registered)

as well as:

Single passage, to enable access of a vehicle on the loop

(Single Passage card works as an unlimited season card)

(up to 83 cards can be registered)

The operator's cards can be set with the Deneb card menu. See 15.2

espas20 I - User Manual

rel. 11-2012

https://appceso.com

PAG. 25
