Power Linking
For the maximum number of EZ Link Par Q4 BT products that you can power link at each voltage, see the User Manual
or the sticker on the product.
Fuse Replacement
1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the safety cap out of the housing.
4. Remove the blown fuse from the clip on the front of the safety cap and replace with a fuse of the exact same
type and rating.
5. Re-insert the fuse holder and reconnect power.

Battery Power

The EZ Link Par Q4 BT comes with a rechargeable lithium battery for cable free operation.
Charging the Battery
The battery charges whenever the EZ Link Par Q4 BT is plugged into the external charger and the charger is plugged into
a power source. If the product is plugged in and not in operation, make sure the product is turned off.
• When using the multi-charger, charge the EZ Link Par Q4 BT while the unit is powered OFF.
• The LED indicator light will flash if you overpower your units.
Battery Life Indicator
The indicators on the LED Menu Display show how much battery life remains available. The drawing below provides a
key to reading the battery life indicators.
Battery Run Time
Maximum Run Time (all colors on)
Up to 8 hours
Control Panel Description
Button Function
<MENU> Exits from the current menu or function
<UP> Navigates upwards through the menu list and increases the numeric value when in a function
<DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function
<ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function
Menu Map
Mode
4Ch
DMX Mode
8Ch
Static Colors C--
Automatic
P--
Programs
Auto Speed S--
Dimmer d--
Sound-
Snd
Active Mode
Sensitivity SEnS
Custom
u--
Color Mixing
EZ Link Par Q4 BT QRG Rev. 2
QUICK REFERENCE GUIDE
100%
Programming Levels
d 1–509
C 1–15
P 1–5
S. 1–100
L. 1–255
Snd1–5
u 0–100
r. 0–255
G. 0–255
75%
50%
Description
4-channel DMX mode
8-channel DMX mode
Static colors
Automatic programs
Program speed for P 1–5
Dimmer
Sound-active programs
Sound sensitivity
Custom static colors combine red, green, blue, and amber
25%
Recharge Time
7.5 hours
