7. Installation and start-up of the equipment

7.1 Unpacking

Verify the packaging is not damaged.
Unpack the equipment and its components carefully. Verify none of the components is damaged.
Verify that none of the components described in Components of the system in operation and Components in installation
kit described in Section 4.7 is missing.

7.2 Location of the equipment

The equipment is self-supporting. To lift or move the equipment, hold it by the base. Always keep the equipment upright.
Do not overturn the equipment.
IMPORTANT! Before the installation, take into account the Environmental conditions and location of the
equipment, Electrical requirements, Feed water requirements and the Dimensions and weight described in Chapter 4.

7.3 Installation of the equipment

7.3.1 Hydraulic connections and installation of switch level
A flexible tube and a tube cutter are provided with the equipment to make the hydraulic
QC (Quick Connect) connectors are installed in the equipment. To connect and disconnect this type of connectors,
follow these steps:
-
To connect the tube, simply insert the tube into the QC connector (Figure 7.1) until limit stop.
-
To disconnect the tube, first press the central washer of the QC connector while pulling the tube
in the opposite direction.
Important!
Before disconnecting a QC connection, make sure that the connector is not
under pressure. If the hydraulic circuit of the equipment is pressurized, the QC connectors will offer resistance to being
disconnected.
Important!
The tubes inserted in QC connectors have to be cleanly cut. The cut must be perpendicular to the
length of the tube. The section of the tube inserted in the connection will be smooth, without scratches. Any bevel or
irregular cut will make the connection imperfect and can present risks of water leakage
connections.
Figure 7.1
.
13/31
