4.8 Hydraulic connections and switch level connection

Locate the equipment so that the hydraulic connections are not compromised.
Avoid tight tubes.
Hydraulic connections
Connection to water supply
(Requirement)
Connection [IN] of the
equipment
Connection [TANK] of the
equipment
Connection [Rej] of the
equipment
Connection [Type II] of the
equipment
Connection [Bot] of the
equipment
a
QC: Quick Connect
Figure 8.1
Shut-off valve with a 3/8" male threaded gas terminal
An easy accessible shut-off valve should be located before the water inlet into the
equipment in case the water supply needs to be interrupted.
From water supply to equipment
a
Connector QC
Tube 1/4" (Outer diameter)
From equipment to atmospheric tank.
a
Connector QC
Tube 1/4" (Outer diameter)
From equipment to drainage
a
Connector QC
Tube 1/4" (Outer diameter)
Electrical connection to switch level.
Not used
10/31
