Electrical connection

Connect the compact AS-i E-STOP safety module via the M12
connector to the AS-i system. The supply comes from the AS-i
system.
Do not connect the AS-i potential to an external potential.
M12 connector
3
AS-i -
4
5
1
2
AS-i +
M12 connector
AS-i +
AS-i -
Data bits
Data bit
Connector
Activated input channel
I-1(p)
I-2(n)
I-1(p) and I-2(n)
none
Activated alarm output
O-1
The code words 0000, XX00 and 00XX cause the AS-i safety monitor
to switch the installation into the safe state.
For details on the effect of the corresponding data bits on the trans-
mission sequence please refer to the configuration software manual
(see the chapter "Monitoring devices").
Pin
1
3
D0 D1
I-1/O-1 I-1
Bit sequence D3-D0
XX00
00XX
0000
XXXX
Bit sequence D3-D0
XXX1
1
D2 D3
I-2 I-2
M12 connector
LED red/LED green
(cannot be seen
when the housing
is closed)
LED red
alarm output
Do not change
1
the electrical
connections!
X = don't care
