DMX Linking

The Ovation F-55FC will work with a DMX controller using a 5-pin DMX serial connection. A DMX Primer is available from
www.chauvetprofessional.com.
DMX Connection
The Ovation F-55FC uses a 5-pin DMX for its DMX personalities: 1 Ch, 3 Ch, 5 Ch, 7 Ch, 10Ch, 12Ch, 13Ch, 15Ch, and
HSV. See the User Manual for information about connecting and configuring the product for DMX operation.
Master/Slave Connection
The Ovation F-55FC uses the DMX data connection for its Master/Slave mode. See the User Manual for information
about how to connect and configure the product for master/slave operation.
RDM (Remote Device Management)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate bi-directionally
along existing DMX cabling. Check the DMX controller's User Manual or with the manufacturer as not all DMX controllers
have this capability. The Ovation F-55FC supports RDM protocol that allows feedback to make changes to menu map
options. Download the User Manual from

Virtual Color Wheel

The Ovation F-55FC includes a feature called the Virtual Color Wheel (VCW). This feature is available as a stand-alone
control mode for manual use and also as a control channel in select DMX personalities. Over 30 pre-mixed colors,
custom blended by our engineers, are available to call up for easier programming.
The DMX values used to mix these colors are provided below. You may adjust the overall intensity of the Ovation fixture
in order to more closely replicate colors you are familiar with. A chart is available on our website
www.chauvetprofessional.com
purposes only and is not a representation that our pre-mixed colors match any of the gel colors listed.
Color Chart
DMX Channel Value
000  005
006  013
014  021
022  028
029  035
036  043
044  051
052  059
060  067
068  075
076  083
084  091
092  099
100  107 C1250 - Md Red Amber
108  115 C1060 - Dk Red Amber
116  121
122  130
131  138
139  146
147  154
155  162
163  170
171  178
179  186
187  194
195  202
203  210
211  218
219  226
227  234
235  242
243  250
251  255
The colors above are simulated renditions of the color output produced as compared to other
similar incandescent products. Chauvet makes no guarantee of the color output accuracy.
Ovation F-55FC QRG Rev. 3
QUICK REFERENCE GUIDE
