6 Technical Data
Repeater
Ord. code
Electromagnetic compatibility (EMC)
Immunity for industrial environments according
EN 61000-6-2:2001
Electrostatic discharge (ESD)
Electromagnetic field
Fast transients (burst)
Surge
Line-conducted disturbances
Interference emissions
Climatic ambient conditions
Ambient temperature
Storage temperature
Relative humidity
Mechanical ambient conditions
Vibration (during operation)
Vibration (during transport)
Protection class
Weight
Dimensions (W × H × D)
Housing material
46
OZD Modbus Plus G12
943 740-021
Satisfies EN 61000-4-2; 4 kV contact discharge, 8 kV air discharge
Satisfies EN 61000-4-3; 10 V/m (80 MHz - 1000 MHz)
Satisfies EN 61000-4-4; 2 kV power line, 1 kV data line
SatisfiesEN 61000-4-5; 1 kV data line
Satisfies EN 61000-4-6; 10 V (150 kHz - 80 MHz)
Satisfies EN 55022; Class A
Satisfies FCC CFR47 Part 15; Class A
0 °C to + 60 °C (IEC 60068-2-1, IEC 60068-2-2)
– 40 °C to + 70 °C (IEC 60068-2-14)
<95 %, non-condensing (IEC 60068-2-30)
10 to 58 Hz, 0.075 mm displacement;
2
58 to 150 Hz, 10 m/s (1 g) acceleration (IEC 60068–2–6)
5 to 9 Hz, 3.5 mm displacement;
2
9 to 500 Hz, 10 m/s (1 g) acceleration
IP 40
approx. 620 g
40 × 133 × 77 mm
Die-cast zinc
OZD Modbus Plus G12-1300
943 821-021
