EN
Key
br = brown
1
Control Box
2
ISO BUS terminal
3
Adapter cable
4
Cinch plug
5
Video signal 1
6
Video signal 2
7
Video GND
You can find the pin configuration of the
terminal in the operating manual for the
monitor.
DE
Legende
br = braun
1
Schaltbox
2
ISO BUS Terminal
3
Adapterkabel
4
Cinch-Stecker
5
Video-Signal 1
6
Video-Signal 2
7
Video-GND
Die Pin-Belegung des Terminals finden Sie
in der Bedienungsanleitung des Monitors.
RVNH2
9600000244
1
4
3
4
3
1.
1
2.
FR
Légende
br = marron
1
Boîte de commande
2
Terminal BUS ISO
3
Câble adaptateur
4
Fiche Cinch
5
Signal vidéo 1
6
Signal vidéo 2
7
GND vidéo
Pour connaître l'affectation des broches du
terminal, consultez le manuel d'utilisation
du moniteur.
ES
Leyenda
br = marrón
1
Caja de distribución
2
Terminal de BUS ISO
3
Cable adaptador
4
Clavija Cinch
5
Señal de vídeo 1
6
Señal de vídeo 2
7
Video GND
En las instrucciones de uso del terminal
podrá encontrar la asignación de pines del
mismo.
2
br
br
14
3.
7
8
16 14
5
6 7
5.
4.
PT
Legenda
br = castanho
1
Caixa de distribuição
2
Terminal ISO BUS
3
Cabo adaptador
4
Ficha Cinch
5
Sinal de vídeo 1
6
Sinal de vídeo 2
7
GND Vídeo
No respetivo manual de instruções do
terminal encontrará a ocupação dos pinos.
IT
Legenda
br = marrone
1
Scatola di comando
2
Terminale ISO BUS
3
Cavo adattatore
4
Spina cinch
5
Segnale video 1
6
Segnale video 2
7
GND video
Per la disposizione dei PIN del terminale,
consultare il manuale di istruzioni del
monitor.
3
5
1
7
8
13
14
19
20
26
21
25
