3.2 Quinta MU 23/22/21/MU 23 V/MU 21 V and Quinta MU 33/31 Microphone Units
How to connect the gooseneck microphone to Quinta MU 23/22/21/MU 23 V/MU 21 V
There are gooseneck microphones with an LED available to connect to the Quinta MU 23/22/21/
MU 23 V/MU 21 V microphone unit.
• Take the gooseneck microphone by the shaft, put it into the connection for gooseneck microphones
and press the shaft downwards until it locks in place.
• If you want to remove the gooseneck microphone, press into the opening for unlocking the goose-
neck microphone
phone by taking it by the shaft and pulling.
Switching on
• The microphone unit is switched on by pressing the microphone button. The microphone button
will light up for a moment and the operating control LED
When the connection to the Quinta CU control unit has been established, the buttons of the
microphone unit will illuminate white.
• To activate the microphone or to allocate the microphone unit to a free channel of the Quinta CU
control unit, press the microphone button
microphone button will illuminate green (normal operating mode) or red (request-to-speak mode).
Switching off
• If you press the microphone button
switched off.
• You can switch off all the active Quinta MU microphone units within the range of the Quinta CU
control unit when you press the standby button
• Furthermore, the microphone units are switched off automatically, when they do not receive a
signal from the Quinta CU control unit for more than 3 minutes.
Operating modes
The different operating modes such as "Normal", "Push-To-Talk" or "Voice Activation" are adjusted
with the Quinta Conference software for all microphone units. The standard operating mode is
"Normal". Please refer also to the appropriate "Quinta Conference Software" or "Quinta Web Server"
manual.
Powering / operating time
• The microphone units have an integrated rechargeable battery allowing an operating time of
approx. 20 hours.
• As soon as the battery charge is too low for a satisfactory operation, the operating control LED
on the rear of the microphone unit will flash. The remaining time of operation is around 60 minutes.
• The charging state of the microphone units can be displayed with the Quinta Conference software
on a PC connected to the Quinta CU control unit or via the integrated web server. Furthermore, it
can be displayed on an external media control system connected to the Quinta CU control unit.
• The Quinta MU microphone units can be powered via the external CA 2459 mains charger adapter,
which is connected to the DC socket
• While the CA 2459 mains charger adapter is connected, the rechargeable battery of the micro-
phone unit is charged.
Quick Start Guide Quinta – How to Operate the System
with the supplied tool or a similar thin tool. Remove the gooseneck micro-
for more than 2 seconds the microphone unit will be
on the rear of the microphone unit.
on the rear will illuminate green.
once again. Depending on the operating mode, the
of the control unit for more than 3 seconds.
