Load Energized Time
When either of the two sources is connected to the load and
the connected source is available, this counter will start log-
ging the time in hours. This counter will count up to 9999
hours and then turn over to 0000. It can be reset to zero in
the Program Mode.
Total Number of Transfers
This counter logs the number of transfer cycles that occur.
This counter will count up to 9999 hours and then turn over
to 0000. It can be reset to zero in the Program Mode.
Reason/Date/Time for the 16 Most Recent Transfers
The 16 most recent transfer events are stored in history and
may be viewed at the LCD Display as follows:
Use the Step/Enter pushbutton to step to the "TRANSFER
HISTORY" message.
Press the Increase pushbutton to display the most recent
transfer event (T01) along with the type and cause of the
event.
Press the Decrease pushbutton to display the date and time
of the event. Continually pressing the Decrease pushbut-
ton will cycle the display between the event display and
the date/time of event display.
Press the Increase pushbutton to display the next most
recent transfer event (T02).
Pressing the Step/Enter pushbutton, while viewing any of
the transfer history displays, will exit the Transfer History
displays.
3.1.4 Setpoints Display
The Setpoints Display indicates presently programmed set-
points. The setpoints can be altered with valid password
entry. Keep in mind; if an optional ATC-300 Controller fea-
ture was not originally ordered and programmed, it will not be
displayed. Refer to Section 6 for more details on setpoints.
3.1.5 Help Display
This display presents moving language messages, explana-
tions, and prompts to assist the operator. When the Help/
Lamp Test Pushbutton is pressed and released a second time
during the scrolling of a message, the message is aborted.
