Operations
KODAK PICTURE CD / JPEG
CD OPERATIONS
1. PLAY MODES
Press repeat button during play to change the
play modes. During playback, press STOP to enter
preview mode.
∙ "REP 1" > repeats 1 track
∙ "REP DIR" > repeats all tracks of actual folder
∙ "REP ALL" > repeats all tracks in cd/dvd
∙ "REP APA" > cancel any repeating mode
2. SKIP TO NEXT/PREVIOUS PICTURE
Press NEXT button to skip to the next picture or
PREV button to the previous picture.
If no key is pressed for a few seconds, it will skip to
next picture automatically.
3. PICTURE ROTATIONS
Press RIGHT and LEFT navigation buttons to
rotate the picture Clockwise and anti-clockwise
respectively.
4. PICTURE FLIPS
Press UP/CH+ navigation button to flip the picture
vertically. Press DOWN/CH- navigation button to
flip the picture horizontally.
5. PICTURE ZOOM IN/OUT
Press ZOOM button continuously ,the picture zooms
in by 2, 3, 4 times or zooms out by 1/2, 1/3, 1/4
the original size. Press this button once more when
the picture getting 1/4 size to return to the normal
play. If the picture is enlarged, you may use the
navigation buttons to view blocked parts of the
picture.
6. SLIDE SHOW TRANSITION MODES
During slide show playback, press the PROGRAM
button cyclically to select one of the modes to
play.
10
P/N SWITCH
(ONLY BOX TV MODEL)
Press P/N button on the remote to directly change
the TV mode among PAL, NTSC and AUTO.
EXTERNAL MEMORY MEDIA
OPERATION (USB&SD/MMC CARD)
Prepare the player for External Memory media op-
eration plug a USB data traveller into the USB port
or insert the SD/MMC card to SD/MMC card slot.
MODEL BOX:
Turn the FUNCTION control to the position DVD and
press MODE button to select between DISC, CARD
and USB.
MODEL BOX TV:
Turn the FUNCTION control to the position
DVD/DVB and press DVD/DVB button to select DVD
Mode. Once in DVD mode, press DVD/USB/CARD
button on the remote to select the USB or CARD
according to the device you wish to explore.
After successfully detected and read, all folders
will be shown on the screen, select your favorite
folder with the navigation buttons,press SELECT or
OK button to confirm.
Choose the desired track also by navigation buttons
and confirm by pressing SELECT or OK button.
Note: The player can successfully play the music files
with USB 1.0 and USB 2.0 storage device.
