TROUbLEShOOTING GUIDE

Problem
Short Run Time
Sluggish Action
Controls Reversed
Motor/ESC overheat
Doesn't Operate
Poor Range
The system will not connect
The receiver goes into failsafe
mode a short distance away
from the transmitter
The receiver quits responding
during operation
Receiver loses its bind
What this Warranty Covers
Horizon Hobby, Inc. ("Horizon") warrants to the original purchaser
that the product purchased (the "Product") will be free from defects
in materials and workmanship at the date of purchase.
What is Not Covered
This warranty is not transferable and does not cover (i) cosmetic
damage, (ii) damage due to acts of God, accident, misuse, abuse,
negligence, commercial use, or due to improper use, installation,
operation or maintenance, (iii) modification of or to any part of the
Product, (iv) attempted service by anyone other than a Horizon Hobby
authorized service center, or (v) Products not purchased from an
authorized Horizon dealer.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION, AND
HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. THE PURCHASER ACKNOWLEDGES THAT
THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY
MEET THE REQUIREMENTS OF THE PURCHASER'S INTENDED USE.
Purchaser's Remedy
Horizon's sole obligation and purchaser's sole and exclusive remedy
shall be that Horizon will, at its option, either (i) service, or (ii) replace,
any Product determined by Horizon to be defective. Horizon reserves
the right to inspect any and all Product(s) involved in a warranty claim.
Service or replacement decisions are at the sole discretion of Horizon.
Proof of purchase is required for all warranty claims. SERVICE OR
REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
PURCHASER'S SOLE AND EXCLUSIVE REMEDY.
10
Possible Cause
• Battery damaged/not charged
• Motor dirty or brushes worn
• Motor dirty or brushes worn
• Bind in drivetrain
• Vehicle battery is not charged
• ST. REV or TH. REV
• Over-geared
• Transmitter batteries low
• Transmitter powered off
• ESC powered off
• Vehicle battery is not charged
• Transmitter batteries low
• Transmitter antenna is damaged or loose
• Receiver antenna damaged
• Transmitter and receiver too near each other
• T ransmitter and receiver too near large
metal objects (vehicles, etc.)
• T ransmitter accidentally put in bind mode so
receiver is no longer bound
• C heck the receiver antenna to be sure it is
not cut or damaged
• Low battery voltage
• L oose or damaged wires or connectors
between battery and receiver
• T ransmitter accidentally put in bind mode,
ending bind to receiver

LIMITED WARRANTy

• Check/change battery
• Check/clean/replace
• Check/clean/replace
• Clean/adjust
• Replace/recharge
• Change switch position
• Install smaller pinion
• Replace/recharge
• Power On
• Power On
• Replace/recharge
• Replace/recharge
• Check/tighten
• Check/repair/replace
• Move transmitter 8–12 feet (2.4–3.6m) from receiver
• Move away from large metal objects (vehicles, etc.)
• Rebind transmitter and receiver
• Contact Horizon Product Support
• M ake sure receiver antenna is in an antenna tube and is
above vehicle
• Completely recharge battery
• D o a check of the wires and connection between battery
and receiver. Repair or replace wires and/or connectors
• Bind transmitter to receiver

Limitation of Liability

HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL
OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION
OR COMMERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER
SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT,
NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF LIABILITY,
EVEN IF HORIZON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. Further, in no event shall the liability of Horizon exceed
the individual price of the Product on which liability is asserted. As
Horizon has no control over use, setup, final assembly, modification or
misuse, no liability shall be assumed nor accepted for any resulting
damage or injury. By the act of use, setup or assembly, the user
accepts all resulting liability. If you as the purchaser or user are not
prepared to accept the liability associated with the use of the Product,
purchaser is advised to return the Product immediately in new and
unused condition to the place of purchase.
Law
These terms are governed by Illinois law (without regard to conflict
of law principals). This warranty gives you specific legal rights, and
you may also have other rights which vary from state to state. Horizon
reserves the right to change or modify this warranty at any time
without notice.
WARRANTy SERVICES
Questions, Assistance, and Repairs
Your local hobby store and/or place of purchase cannot provide
warranty support or service. Once assembly, setup or use of the
Product has been started, you must contact your local distributor
or Horizon directly. This will enable Horizon to better answer your
questions and service you in the event that you may need any
Solution
