Vibration acceleration value for drilling: ahD = 4.56 m / s2
Vibration acceleration value at impact drilling: ah ID = 9.24 m / s2
4. Preparation for operation.
4.1. Charge the lithium rechargeable battery.
Remove the battery from the handle, press the button down to do this. Pay attention to mains voltage
when charging the battery! The mains voltage must match the data on the charger label. Appliances
marked with 230V can also be powered with a voltage of 220V. The green LED will be switched. Squeeze
the battery into the charger.
See explanation table:
Red LED
Off
On
Off
If the battery can not charge, check the following:
• contact voltage
• makes good contact with the charger contacts
If the battery can not be charged again, visit an authorized RAIDER service center.
To make sure that the lithium-ion rechargeable battery will last longer, you must recharge it
immediately. You must recharge the battery when you notice that the power of the cordless tool is
decreasing.
4.2. Battery capacity indicator.
Press the button on the battery capacity indicator. It shows the status of the battery charge using 3
LEDs.
All 3 LEDs glow: The battery is charged
2 LED (s) are on: The battery has enough residual charge
1 LED is on: The battery is running low, charge the battery
All LEDs blink: The battery has completely broken down and defective. Do not use or charge a
defective battery.
Indicator status
Green LED Ready for use
The charger is connected to
On
the mains and is ready for use;
there is no
battery pack in the charger
Off "Charging
The charger is charging the
battery pack "
On "The battery is charged and
ready for use.
Charging time for 2.0 Ah
battery: 60 min
Action:
Take the battery pack out of the
charger. Disconnect the charger
from
the mains supply."
Explanations and actions
