MoniTrace Remote Monitoring Module (RMM2)
L1
L2
L3
N
K1
self-regulating
self-regulating
heating cable
heating cable
Circuit breaker configuration may vary according to local standards / requirements
Depending on the application one or three pole contactors may be used
The MoniTrace 200N unit independently controls two groups of trace-heating circuits. Remote
Monitoring Modules (RMM2) collect RTD inputs and communicate with the MoniTrace 200N central
control and monitoring unit using a single RS-485 bus.
Overview of Installation Procedure for the RMM2-EX-E
A. Mount RMM2 enclosure and install cables.
B. Connect power and earth wiring and select voltage operating range.
C. Connect RTD cables to the RMM2.
D. Select RS-485 address for the RMM2 and connect the RS-485 bus cables.
E. Initialise or update the MoniTrace 200N network and assign settings for each RTD (using the
MoniTrace 200N control panel).
Note: Installation to be performed by suitable trained personnel.
Note: Keep the MoniTrace Remote Monitoring Module clean and dry prior to installation to avoid
damage to internal components.
Note: When RMM2-E is used for DIN-rail installation in a local customised panel or enclosure,
must be added 10 earth terminals for earthing of RTDʼs and power cables. Terminals should
accept wires from 0.2 to 4 mm
max.
