Parts List - DK2 POWER OPC505AE Guide De Montage

NO. DESCRIPTION
1 Penta-blade rod
2 Triangle blade
3
4 M10*25 thinhead screw
5 Bearing 1507
6 Pulley dia. 200
7 B-belt 940
8 Engine
9 Adjust plate 4-0
10 D Pin dia. 10*85
11 Tow bar
12 Belt cover
13 Pulley dia. 125
14 Washer 2-0
15 M8*25 screw
16 Bearing 6306-2RS
17 Lock nut M35*1-5
18 Blade push-plate
19 Key way 8*7*60
20 Longe blade spacer
21 Bearing base
22 Fan plate
23 Blade plate
24 Anvil
25 Bottom frame
26 Switch
27 Battery
28 Cover fixing plate
29 Rear frame
30 Rubber pad
31 Oil bean cover
32 Oil feed filter
33 Chain
10 | OPC505AE man. v.210330
ASSEMBLY

PARTS LIST

QTY. NO. DESCRIPTION
1 34 Tank
1 35 Oil outlet filter
36 1.5 inch interface
1 37 Oil outlet interface
1 38 Pin dia. 3.5*40
1 39 Nut M24
1 40 dia. 25 washer
1 41 Wheel 16*8.0-7
1 42 Flange
1 43 Seal dia. 25*47*7
1 44 Bearing 6205
1 45 Wheel pipe axle
1 46 Battery box
1 47 Baseframe plate
1 48 Mouth frame
1 49 Feed rubber
1 50 Foot angle plate
1 50A Pipe
1 50B Supporting spring
1 50C Spring
1 51 Feed hopper
1 51A Emergency panel
1 51B Movable plate
1 52 Switch valve
1 53 Speed valve
1 54 Spring
1 55 Cover
1 56 Short blade spacer
1 57 Interfal rod
1 58 Main axle
1 59 Plate blade
1 60 Bearing FL206
1 61 Pulley A dia. 90
QTY. NO. DESCRIPTION
1 62 Belt A dia. 500
1 63 Pin 8*7*30
1 64 Rubber seal
1 64A Preforming
1 64B Pulling rivet
1 64C Spring
1 64D Switch box
1 64E Rubber seal
1 65 Emergency stop
1 66 Hopper block plate
1 67 Push bar
1 68 Pump joint
1 69 Pump
1 70 Pump fixing plate
1 71 Pump pulley
1 72 Motor
1 72A Ratchet rack
1 72B Ratchet
1 73 Top cover
1 74 Top body
1 75 Screw hook
1 76 Bottom discharge
1 77 Top discharge
1 78 Fasten handle
1 79 Reflect cover
1 80 Seal dia. 72*30*10
1 81 Protective plate
1 82 Stop bar
1 83 Oil seal
1 84 Tension pulley
1 85 Flower bolt M12*85
1 86 Adjustable feet
1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
