Lumilight Led - Zephyr Tempest I Guide D'utilisation

P R O
Maintenance
T E M P E S T I
U N D E R - C A B I N E T

LumiLight LED

In the unlikely event that your LumiLight LED fails, please contact Zephyr to order replacement parts.
See the list of parts and accessories page for part numbers and contact information.
LED Removal (FIG. G):
1. Remove baffle filters.
2. (If applicable) remove both side spacer panels by 2 screws for each spacer panel.
3. Remove light panel by 4 screws.
4. Disconnect LED light quick connector.
5. Push in the two side clips on the ends of the LED light.
6. Push LED light through the light panel opening.
Push the clip
FIG. G
32 Tempest I Use, Care, and Installation Guide
