Pre-Operation (continued)

Assembly

1

Wheel Assembly

□
Install one shoulder bolt (B), one washer (D), and
one nut (C) for each wheel (E) using the bolt holes
provided in the wheel bracket. The shoulder bolt
will install from the outside of the wheel through
the hole in the wheel bracket. Tighten securely
with the washer and nut positioned on the inside of
the wheel bracket.
2

Installing the Air Intake Filter

□
Remove the plastic plug (1) from the compressor
head (2). Remove the air intake filter (3) from the
poly bag and thread it into the compressor head
(2), as shown.
D
C
E
B
10
1
2
3
