screw (10).
If different angle settings are required, the
turntable (8) may be secured in position using
only the locking screw (10).
Lightly press the machine head down while at
the same time pulling the retaining pin (23) out
from the motor mounting; this causes the saw to
move down to the lower working position. Turn
the safety pin (23) through 90° so that the
machine head remains unlocked.
Swing up the machine head.
When the tightening screw (22) is loosened, you
can tilt the machine head to the left by up to 45°.
Check the mains voltage against the voltage
details on the rating plate to ensure they are
identical and plug in the machine.
6.4 Precision adjustment of the stop for crosscut
90° (Fig. 19/20)
Lower the machine head and fasten in place with
the safety pin (23).
Slacken the tightening screw (22).
Place the angular stop (a) between the blade (5)
and the turntable (8).
Slacken the counternut (b) and adjust the
adjustment screw (c) until the angle between the
blade (5) and the turntable (8) equals 90°.
Retighten the counternut (b) to secure this
setting.
6.5 Precision adjustment of the stop for miter cut
45° (Fig. 19/20)
Lower the machine head and fasten in place with
the safety pin (23).
Fasten the turntable (8) in 0° position.
Undo the tightening screw (22) and use the
handle (2) to tilt the machine head to the left until
it coincides at 45°.
Place the 45° stop angle (f) between the blade
(5) and the turntable (8).
Slacken the counternut (d) and adjust the
adjustment screw (e) until the angle between the
blade (5) and the turntable (8) equals 45°.
Retighten the counternut (d) to secure this
setting.
6.6 Sawdust extraction (Fig. 18)
The saw is equipped with an extractor port (31)
for sawdust and chips.
This means that it can be connected to all
extractors with ease.
Never use the equipment without the suction
function. Regularly check and clean the suction
channels.
24.09.2010 8:48 Uhr Seite 17
6.7 Changing the saw blade (Fig. 7/14/15)
Pull the mains plugs, the saw blade must come
to a complete standstill.
Set the saw to crosscut mode (see 6.2.1).
Undo the two Allen screws (32) and remove the
splitter (30) including the saw blade guard (17).
Remove the Philips screws (33) and the table
insert (34).
Lock the outer flange (35) using the supplied
face spanner (21) and turn the hexagonal screw
clockwise using the socket wrench (19)
(important: left-hand screw-thread).
Take the saw blade (5) off the inner flange and
pull it out upwards through the slit in the saw
bench (16).
Thoroughly clean the outer and inner flanges and
the motor shaft before you fit and secure the new
saw blade. Important. The cutting angle of the
teeth (i.e. the direction of rotation of the saw
blade) must coincide with the direction of the
arrow on the housing.
Refit and secure the table insert (34), splitter (30)
and saw blade guard (17).
When you secure the splitter (30) ensure that the
distance between the teeth of the saw blade and
the splitter is min. 3 mm and max. 5 mm (Fig. 7).
Check to make sure that all safety devices are
properly mounted and in good working condition
before you begin working with the saw again.
7. Operation
After every new adjustment we recommend you
to make a trial cut in order to check the new
settings.
Important: The machine is fitted with an overload
switch (Fig. 17/Item b). If the machine is
overloaded, it will cut out automatically.
You must wait a few minutes for the machine to
cool before restarting. Then press the overload
switch (b) again and the machine is ready for
use.
7.1 Use as a bench saw (Fig. 1-9)
Setting the saw to bench mode (see 6.2.2)
Take extra care when starting the cut.
7.1.1 On/Off switch (Fig. 4)
The saw can be switched on by pressing the
green pushbutton (a). Wait for the blade (5) to
reach its maximum speed before starting the cut.
The red pushbutton (b) has to be pressed to
switch off the saw.
