Eaton RASP Instructions D'utilisation page 4

1a
110 mm (4.33")
1b
4 x M6
173 mm (6.81")
2
⌀
6.2 mm (0.24")
3
4/16
110 mm (4.33")
⌀
~ 6 mm
(~ 0.24")
2 x / 4 x M6
1.3 Nm
(11.51 lb-in)
0
1a
1b
4 x M6
1.3 Nm
(11.51 lb-in)
4 x DIN 127, M6
3
Emergency On Call Service: Local representative
USA: EatonCare at
245 mm (9.65")
245 mm (9.65")
4 x DIN 125, M6
0
1.3 Nm
(11.51 lb-in)
Eaton.eu/aftersales or +49 (0) 180 5 223822 (de, en)
Eaton.com/eatoncare or 877-386-2273
