technIcal Data
clock accuracy
Dimensions
Permissible belt widths
Belt length (15 mm standard belt)
max. shutter surface area
note:
The specifications provided are recommended values and apply to ideal installation
situations. Due to existing site conditions, the values may be different.
Only use the product in combination with shutter belts with the dimensions mentio-
ned above. Wrong shutter belt lengths and widths will result in damage. Replace the
old shutter belt when the requirements are not met.
approx. +/- 1 minute / month
see page 170
15 mm (small belt)
5.5 m at belt thickness of 1.0 mm/
4.3 m at belt thickness of 1.3
4.0 m light shutter
