Part names and functions
11 Tuner control buttons
ST/MONO
Use to switch the sound mode between stereo and
monaural. (page 26)
12 OPEN/CLOSE
Use to open or close the disc tray (page 20).
13 Sound control buttons
Adjust the sound quality (page 16).
14 RANDOM
Press to randomize order play setting from a CD, iPod or USB
(page 21).
15 REPEAT
Press to change the repeat play setting from a CD, iPod or
USB (page 21).
16 Volume control buttons
Use to set the listening volume (page 15).
17 DIMMER
Dims or brightens the display. The brightness can be
controlled in four steps (page 15).
Note
• This unit does not use the RDS buttons.

Speaker system

1
2
1 Tweeter
2 Woofer
3 Bass Reflex Duct
4 Speaker Terminals
Important
• Speaker grille can be removed.
• Make sure nothing comes into contact with the speaker
diaphragms when you remove the speaker grilles.
• Both speakers can be used on either the right or the left
side.
Detatching and replacing the front
grille
The front grille of this speaker system is removable. Proceed
as follows:
1 Grab the bottom of the grille, and gently
pull it toward you to remove the bottom
portion.
2 Next, grab the top part of the grille and
gently pull it toward you to remove the top
portion.
To install the grille, align the projections on the speaker with
the receptacles on the top and at the base of the grille and
push them into place.
02
3
4
9
