The cartridge holder can be installed in a few simple steps:
1.
Pull the release knob and push the fluid level sensor assembly to the left.
2.
Loosen the locking screw by turning it counter clockwise.
3.
Rotate the cartridge holder outward and pull it up to remove from the
machine.
4.
Install new cartridge holder in the reverse order.
5.
Pull release knob to rotate fluid level sensor assembly back into position.
RELEASE KNOB
FLUID LEVEL
SENSOR
Figure 16.0 Cartridge Holder
20
CARTRIDGE HOLDER
LOCKING SCREW
