5.5.3 Exemplary settings
Example 1 is the factory setting
ds-1
ds-2 Panel option
ds-3 Ch. voltage
ds-4 Ch. voltage
ds-5 Frequency
ds-6 Search mode
ds-7 AC-in Limit
ds-8 Store setting
Example 1: (factory setting)
1 No panel or remote
switch connected
2 No panel or remote
switch connected
3, 4 GEL 14.4 V
5 Frequency: 50Hz
6 Search mode off
7 AC-in Limit 16 Amp
8 store setting: off→ on→ off
Store the settings (ds-3 to ds-7) by changing switch ds-8 from 'off' to 'on', and then back to
'off'.
The LED's 'charger' and 'alarm' will flash to indicate acceptance of the settings.
6. Maintenance
The Compact does not require specific maintenance. It will suffice to check all connections
once a year. Avoid moisture and oil/soot/vapours, and keep the device clean.
22
off ds-1
on ds-2
off ds-3
off ds-4
off ds-5
off ds-6
off ds-7
→ ←
ds-8
Example 2
1
2
3,4
5
6
7
8 store setting: off→ on→ off
off
on
off
on
off
off
on
→ ←
No panel or remote
switch connected
No panel or remote
switch connected
AGM 14,7V
Frequency: 50Hz
Search mode off
AC-in Limit
30 Amp
ds-1 on
ds-2 off
ds-3 on
ds-4 on
ds-5 on
ds-6 on
ds-7 off
→ ←
ds-8
Example 3
1 Panel or remote
switch connected
2 Panel or remote
switch connected
3, 4 Tubular plate 15V
5 Frequency: 60Hz
6 Search mode on
7 AC-in Limit
8 store setting: off→ on→ off
16 Amp
