Index
1 General Information........................................2
2 Mounting To Wall.............................................3
3 Electrical Connections....................................4
4 Installation of the solenoid valve and filter .....5
1 G I
ENERAL NFORMATION
This manual includes information on the installation
of Coin Timers with display for showers: CT1Xw,
CT2Xw here onwards are indicated by the term
CTx.
For configuration
appropriate manual.
The CTx Coin Timer is a coin or token timer useful
for offering one or more pay shower services. It
includes 12Vdc outputs for directly controlling the
solenoid valves which regulate the flow of water.
1.1 Symbols used in the manual
Parts of the text which are of particular importance
in regards to the safety or proper use of the product
are indicated by the following symbols:
Risk of danger or injury to persons if
instructions or the necessary precautions are
not followed.
Important information on product use
1.2 CTx Versions
The CTx comes in 2 versions, which can be
selected upon ordering:
1. CT1x version 100-240V is directly powered
with a voltage of 100-240V. When used for
showers, regulation IEC60364-7 allows it to
be installed in "Zone 3" on the condition that
the device is powered by a residual current
circuit breaker with a 30mA threshold. For
greater safety we advise that this version be
installed in "Zone 4", and that a power
supply 12Vdc be used in "Zone 3". See Fig.
1 and Fig. 2 for identification of the zones.
2. CT1x version 12Vdc is powered with a
12Vdc voltage. This version is suitable for
installing the CT1w in places where a safety
extra-low
If used for showers, regulation IEC60364-7
allows the CT1w to be installed in "Zone 3".
00182-M02-04-ML Manuale installazione
1-2 S
HOWERS
and use please
voltage is required.
It comes provided with an external power
supply with 100-240V input, which should be
placed inside an electrical panel in "Zone 4"
where the use of such voltage is permitted. A
power supply device placed in "Zone 4"
should, nevertheless, be powered by a
residual current circuit breaker with a 30 mA
threshold.
see the
Fig. 1: CTx positioning for showers with trays
1.3 Technical features
Size and Weight............
Power supply CT1xw
.
on version 100-
240V.......................:
on version 12Vdc...: 12Vdc, 1.3A
Power supply CT2xw
on version 100-
240V.......................:
on version 12Vdc...: 12Vdc, 2.1A
External power supply, furnished with CT1Xw
version 12Vdc:
Input.....................: 100–240Vac, 50–60Hz
Output.................:
External power supply, furnished with CT2Xw
version 12Vdc:
Pag. 2 / 28
(
: Width x Height x Depth
22,5 x 26,0 x 14,0 cm,
3,1kg
:
100–240Vac,
50–60Hz, 0.35A
:
100–240Vac, 50–60Hz
0.7A
0.35 A
12Vdc 1.3 A
