GB
FEATURES
The FM 400 range comprises remote controls and receivers with
frequency modulation (FM) transmission system.
The outstanding feature of FM lies in the fact that it is particularly
immune to interference and therefore guarantees a constantly good
range for the remote control in most circumstances.
The FM 400 has a variable code of millions of combinations (Rolling
Code), which makes the remote control extremely safe and unclona-
ble by others.
Lastly, there is also a special programmer and PC software available
for the FM 400 range to make management of the installation and
consequently the installer's work easier.
MODELS
The FM 400 range comprises:
FM 402
FM 404
FM 400 SR2
FM 400 RB2
FM 400 R4

GENERAL DESCRIPTION

Fig. 1 Plug-in receiver FM 400 SR2
Fig. 2 Mini receiver FM 400 RB2
Fig. 3 Modular receiver FM 400 R4
Fig. 4 Disabling of remote programming
Fig. 5 Transmitters FM 402 and FM 404
Fig. 6 Opening of remote control and positioning of batteries
Fig. 7 Example of remote programming
2-channel transmitter
4-channel transmitter
Plug-in 2-channel receiver for Telcoma control units
Mini 2-channel receiver with terminal block
Modular 4-channel receiver with terminal block
31
