REPLACING THE LAMP

WARNING:
Replacement of the lamp may be carried out by qualified personnel only. If you are
not qualified, do not attempt to replace a lamp yourself. Refer instead to a qualified
professional.
A hot discharge lamp is under high pressure and can therefore spontaneously
explode. Let the spotlight cool for at least 30 minutes before opening it!
When replacing lamps, use only the model specified in the data sheet! The use of
unsuitable lamps leads to damage or even destruction of the device and voids the
warranty.
Do not touch the glass bulb of the lamp with bare fingers. Contamination, especially
from grease, leads to early malfunction of the lamp.
When replacing the lamp, wear protective glasses and protective gloves!
When carrying out any work, make sure that no foreign bodies enter the housing!
The UV filter for protection against UV radiation is located directly in front of the
lamp. Take care not to damage the UV filter! The UV filter must not be removed and a
damaged UV filter must be replaced immediately! Operation without UV protection or
damaged UV protection is prohibited! There is an immediate risk of injury if the device
is put into operation with a missing or damaged UV filter!
In order to maintain the seal of the OTOS H5 moving head according to protection
class IP65, a new seal must be inserted at the appropriate location after the lamp has
been replaced. Carefully follow each step in the instructions below.
1. Fully disconnect the spotlight from the mains (pull out the mains plug)! Make sure that the
spotlight has cooled down completely!
2. Lock the spotlight head to prevent unintentional twisting (pan and tilt locking).
3. Loosen the 4 Allen screws of the rear head cover (see markings), remove the cover from the
spotlight head, release the safety cable of the cover and place it to one side.
4. Loosen the 4 Allen screws holding the fan unit to the spotlight head (see markings) and hang
them carefully on the safety cable. Ensure that the supply lines are not damaged.
