ENGLISH
Working with "Condominial" logic (Dip 1 = non affecting Dip 2 = OFF)
When the gate is fully opened, it will automatically close after the set Pause time. A Start command given during opening is not affecting. A Start
command given when closing provokes the stop and gate reverse after about 1,5 sec. A Start command or Photocell intervention during pause time
charges it extending the period before automatic closing.
Working with "Sudden closing" (Dip 3 = ON)
In opening step and in pause period, after having passed the photocell, it causes the stop and, after 1,5 sec., gate closing.
WARNING: The modification of working logic can be done only after having switched off and switched on again the board.
Lack of electric power
Following to a temporary lack of electric power, at recovery the first Start command puts in motion opening.
Opening with clock
If the gate opening is controlled by a clock it is necessary to enable Condominial working logic.
13) Technical data
Card dimensions and weight: 170 x 70 x 40 mm – 0,16 Kg
Power supply transformer: 230 / 20Vac – 100VA
Battery charger capacity: 0,2A max.
Blinker power supply: 24V - 10W max.
Relay contact capacity: 30A max.
Motor power supply: 24Vdc - 90W max.
Accessories power supply: 12Vdc - 3 W max.
Working temperature: 0 up to + 60 °C
Pause time regulation: 1 up to 300 seconds
Amperometric Stop regulation: 50 up to 87%
E) Maintenance
Warning: Equipment maintenance is to be performed only and solely by a qualified technician authorized by manufacturer. Any maintenance or
control operation of the equipment is to be performed without Mains voltage.
Ordinary maintenance: Any time you notice it is needed and anyway any 6 months it is advisable to check the working status of the
equipment.
Extraordinary maintenance: If uncommon interventions on the equipment are needed, it is recommended to remove it, in order to allow its
repair in a laboratory by technicians of manufacturer or authorized by him.
Manufacturer declines any responsibility for lacking compliance with above mentioned rules.
17
