Set-up and Start-up
Install the evapora-
tor flask
26
4.5.5

Install the evaporator flask

WARNING Glass breakage!
Serious injuries from shattering and breaking glass.
Check glass devices for damages (stars, breaks, etc.).
Only use perfect glass devices and replace all damaged
glassware as soon as possible.
Work carefully.
CAUTION Unintentionally rotating drive!
Injuries to hands.
Verify that the rotation is displayed.
WARNING Risk of injuries due to retracting or entrapment!
Risk of injury.
A risk of entanglement exists on the movable parts of the unit.
Wear suitable protective clothing for activities on the rotary
evaporator with goggles and gloves.
Install the evaporator flask with a permanent flask clamp on the vapor tube.
2
Figure 4-13: Flask clamp (swing clamp)
1 Jacknut
The correct seating of the swing clamp on the flange of the eva-
porator flask must be observed!
1
2 Swing clamp
Hei-VAP Precision
