Toshiba Super Modular Multi Manuel Technique page 134

Dimensions
TCB-PCDM2E
Vis de borne
Terminal
M3 x 6
Screw M3 x 6
Vis de borne
Terminal
M4 x 6
Screw M4 x 8
TCB-PCMO2E
Terminal
Vis de borne
Screw M3 x 6
M3 x 6
TCB-PCIN2E
Terminal ( Screw M3 )
Vis de borne M3
71
61
55.5
45.5
Trou dia. 4-4
4- 4 hole
79
69
Trou dia. 4-4
4-4ø hole
4-4ø hole
Trou dia. 4-4
12
129
