8. INSTALLATION
ALWAYS USE THE MAIN SWITCH TO ISOLATE THE POWER SUPPLY
01
Mark the fixing points on the wall or ceiling so that they will match
those of the device, or according to the dimensions as indicated
on p.50
Take the indicated free space around the device into account
03
Place the device in the correct position. The appliance can be hung
directly against the ceiling or with threaded rods, the installer has
to provide silencers.
Use a washer between screw head and the appliance.
05
Connect the device electrically.
02
Drill the holes and place the plugs.
Use a plug adapted to the ceiling type.
04
Connect the device hydraulically.
06
Slide the cover around the device and fix.
