Enerpac VSP Série Instructions page 4

Figure 2, VSP Pump Mount
Figure 1, VSP Remote Mount
3/8" NPTF Port
Solenoid B
Solenoid B
3/8" NPTF
Port
Solenoid A
Solenoid A
3/8" NPTF Port
Manual
Manual
3/8" NPTF Plugged for
Override Pin
Override Pin
Pump Mount
1/8" NPTF
Plugged for
Remote Mount
Power Cord* IC43
IC32
3 & 4
Dump
Way
IC43 IC32
3/8" NPTF Plugged for
3 & 4 Dump
Remote Mount
Way
* Remote mount valves come equipped with either a 115V AC
or 24V DC power cord depending on the model number
ordered. The 115V AC cord will have a 3-prong plug at the
end of the cord. The 24V DC will not have any plug.
