Keypad actions and shortcuts
Switch the locator or transmitter on by pressing the
keys function as follows:
Locator keys
K E Y
● S HORT PRESS
Enter the menu
Scroll through locate frequencies
from low to high
Increase and decrease gain in power and
radio modes.
and
RD5100H O+ automatically sets gain to
2
mid-point when pressed
Turn Target Position Indicator mode ON/OFF
Send an iLOC command to a paired
transmitter
Transmitter keys
K E Y
● S HORT PRESS
Enter the menu
Scroll through locate frequencies
from low to high
Take voltage and impedance measurements
using the currently selected frequency
Adjusts the output signal
and
Tip: to scroll through frequencies from high to low, hold
button (applies to both locators and transmitters).
key. Once powered up, the
● ■ ■ ■ ● L ON G PR ESS
Switch power off
–
Rapidly increase and decrease gain steps in
1dB increments
–
Enter the Transmitter power setting menu for
use over iLOC
● ■ ■ ■ ● L ON G PR ESS
Switch Power off
–
Take voltage and impedance measurements
at a standardized frequency
Select standby / maximum standard
power
while pressing the
8

Before you begin

IMPORTANT
This guide is intended to be a quick reference guide. We recommend you read the full
operation manual before you attempt to operate the RD5100H
First use
The RD5100H O+ locator and transmitter can be powered by D-cell alkaline batteries,
2
D-cell NiMH batteries, or by an accessory Lithium-Ion (Li-Ion) battery pack.
To fit the D cell batteries in the locator, open the battery compartment and insert two
D-Cell Alkaline or NiMH batteries, taking care to align the positive (+) and negative (-)
terminals as indicated.
To fit the D cell batteries in the transmitter, unlatch the accessory tray. The battery
compartment is located underneath the transmitter body. Use the turnkey to unlatch
the battery compartment. Insert eight D-Cell Alkaline or NiMH batteries, taking care to
align the positive (+) and negative (-) terminals as indicated.
Alternatively, you can power the transmitter from a mains or vehicle power source
using a Radiodetection supplied optional accessory adapter.
Rechargeable battery packs
Lithium-Ion battery packs are available for both locators and transmitters, providing
superior performance over traditional alkaline batteries. To fit these rechargeable
packs, follow the instructions provided with each pack.
Checking your system software version
If you wish to check which version of software is running on your locator, press and
hold the key when switching the locator on. This information may be asked for
when contacting Radiodetection or your local representative for technical support.
Transmitters automatically show their software version on startup.
System setup
It is important that you set up the system according to regional / operational
requirements and your personal preferences before you conduct your first survey. You
can set the system up using the menus as described below.

Setting up your system

The RD5100H O+ locator and transmitter menus allow you to select or change system
2
options. Once entered, the menu is navigated using the arrow keys. Navigation is
consistent on both the transmitter and the locator. When in the menu, most on-screen
icons will temporarily disappear and the menu options will appear in the bottom left-hand
corner of the display. The right arrow enters a submenu and the left arrow returns to the
previous menu.
O+ locator.
