specIfIcatIons

model number
BTu/hour input (1)
Heating Capacity (2)
electrical Rating (3)
Power Consumption
Fuel Storage Capacity
Flue Size (4)
Width
Height
depth
Weight
(1) Heat output will vary, depending on the brand, type
and quality of fuel and the moisture content. Consult
your dealer for best results.
(2) Based on post 1982 home construction, requiring 35
BTU/Hr. per Sq. Ft.
(3) Install per NFPA 70 and follow all state and local
codes, contact licensed electrical contractor for
assistance.
(4) Install per NFPA 211 and follow all state and local
codes, contact licensed installers for assistance.
Listing label:
Tested to the following standards: UL1482, ASTM E1509,
ULC/ORD-C1482-M1990, and UCL S627-2000

glass specIfIcatIons

This stove is equipped with 5 mm ceramic glass. Replace
glass only with Castle Pellet Stoves ceramic glass. Call
your Servicing Dealer or Castle Stoves at 1-800-345-6007
for replacement parts.
10
hps10
3.7 lbs/hr
1,500 sq. ft.
115 volts, 60 Hz
520 Watts ignition
150 Watts operating
1 bag
3 in.
18.25 in.
34 in.
23.75 in.
186 lbs.
Check for parts online at www.castlestoves.com or call 800-345-6007 M-F 8-5 CST
CAUTION
thIs InstallatIon must conform wIth
local codes. In the absence of local
codes you must comply wIth astm
e1509, (um) 84-hud, ulc/ord-c-1482 and
and ucl s627-2000.
castle pellet stoves, manufacturer of
thIs applIance, reserves the rIght to
alter Its products and/or theIr specI-
fIcatIons wIthout notIce.

unpackIng

Your Castle HPS10 will come fully assembled. Remove
all packing material and tape from the inside of the
firebox. Remove any tape on the outside of the glass.
Open the hopper, remove all packing material and
power cord.
NOTE: MakE surE ThE hOppEr is frEE Of all
fOrEiGN MaTTEr bEfOrE filliNG wiTh fuEl.
fOrEiGN MaTErial will causE auGEr jaMs
aNd will vOid sTOvE warraNTy.
