Manuel de l'utilisateur Easidew Online
A.1

Dimensions



ø25.4 x 2mm
(ø1 x 0.07")
5/8" 18 UNF
Joint de liaison 5/8"
Michell Instruments

10mm
(0.39")

1/8" NPT
96mm


(3.7")
VUE DE FACE
94mm
 
(3.7")
Easidew Online Hygrometer
GRILLE DE CLAVIER
132mm

(5.19")
46mm
 
(1.81")
ø27mm
(1.06")
5/8" 18 UNF


10mm
(0.39")
Transmetteur
1/8" NPT

55.2mm
5/8"-18 UNF
2.2"
Bloc d'échantillonnage
48mm
(1.9")
VUE LATÉRALE
 
10.5mm
(0.41")
46mm
(1.8")
VUE DE DESSUS
Moniteur
Figure 33 Dimensions
ANNEXE A
ø25.4 x 2mm
(ø1 x 0.07")
Joint de liaison 5/8"
5/8"-18 UNF
76mm

(3")
44mm
(1.73")
1/8" NPT

55.2mm
1/8" NPT
2.2"
Bloc
92mm
(3.6")
