The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. While reading the manual you can fold out
the page for comparison and quick reference.
[1-1] Drilling symbol
[1-2] Torque thumbwheel
[1-3] Torque/drilling position marking
[1-4] Gear switch
[1-5] Right/left switch

Changing the battery pack [2]

 Battery pack is ready for use immediately upon
delivery and can be charged at any time.
Removing the battery pack

Press and hold the button [2-1].

Slide the battery pack downwards to remove.
Inserting the battery pack

Slide the battery pack upwards into the machine
like shown in [2] until it engages.

Functional description

[1-6]
[1-7]
[1-8]
[1-9]
[1-10] Bit store
[1-11] LED lamp with capacity indicator

Operation

On/Off switch
Belt clip
Insulated gripping surfaces (grey shaded
area)
Button for releasing the battery pack
2-1
