Technical Data

Welder
Art. No
Degree of protection
Insulation class
Mains voltage U
1
Mains frequency
Maximum rated input current I
Maximum effective input current I
Max. input
Protection, time delay
No-load voltage U
0
Load voltage U
2
max. Welding current
Regulated section Welding current I
Number of switching steps
Switching steps
Duty cycle at max. electricity X *
( 230V )
Material thickness
Wire thickness (Steel)
Flux cored electrode welding
Dimensions L x W x H
Net/gross weight
* The ratio of given duration time/the full-cycle time.
Note 1: This ratio shall be within 0~1, and can be indicated by percentage.
Note 2: In this standard, the full-cycle time is 10 min. For example, if the duty cycle is 60 %, the load-applying
time shall be 6 min and the following no-load time shall be 4 min.
Switch-on time determined at 40°C using simulation
Read and understand the operating
instructions before using the
appliance. Familiarise with the
control elements and how to use the appliance
properly. Abide by all the safety measures stated in
the service manual. Act responsibly toward third
parties.
The operator is responsible for accidents or risks to
third parties.
In case of any doubts about connection and operati-
on refer please to our customer center
1max
1eff
2

Specified Conditions of Use

The flux cored electrode welding device is exclusi-
vely intended for domestic use and is not suitable for
commercial use.
The flux cored electrode welding device is intended
for self-protecting flux cored electrode welding
using the correct wire.
No additional gas is required. The protective gas
is contained in the wire in powdered form, is thus
fed directly into the arc and this makes the device
resistant to wind when used outdoors.
Only wire electrodes which are suitable for the
device may be used.
SG 120 A
20070
IP 21S
H
230 V
50 Hz
13,5 A
4,7 A
230 V ( 3,2 kVA )
16 A
31 V
45 A / 16,25 V
90 A / 18,5 V
230 V ( 90 A )
45 A - 90 A
2
45 A + 90 A
45A / 60 %
90 A / 10 %
1,5 - 5 mm
0,9 mm
Yes
400 x 185 x 305 mm
14 kg / 15,74 kg
