Installation Location

The performance of this scanner is affected by the environment in
which it is installed. Make sure that the location where the scanner is
installed meets the following environmental requirements.
• Provide adequate space around the scanner for operation,
maintenance, and ventilation.
• Provide adequate space in front of the scanner for documents
output after being scanned.
• Avoid installing the machine in direct sunlight. If this is
unavoidable, use curtains to shade the scanner.
• Avoid locations where a considerable amount of dust
accumulates.
• Avoid warm or humid locations, such as in the vicinity of a water
faucet, water heater, or humidifier.
• Avoid locations where ammonia gas is emitted.
• Avoid locations near volatile or flammable materials, such as
alcohol or paint thinner.
• Avoid locations that are subject to vibration.
• Avoid exposing the scanner to rapid changes in temperature. If
the room in which the scanner is installed is cold but rapidly
heated, water droplets (condensation) may form inside the
scanner. This may result in a noticeable degradation in scanning
quality.
• The following conditions are recommended for optimal scanning
quality:
• Room temperature: 10°C to 32.5 °C (50 °F to 90.5°F)
• Humidity: 20% to 80% RH
• Avoid installing the scanner near equipment that generates a
magnetic field (e.g. speakers, televisions, or radios.)
100mm
3.94"
100mm
3.94"
AC Adapter
• Connect only to a power outlet of the rated voltage and power
supply frequency (120 V, 60 Hz or 220-240 V, 50/60 Hz
depending on your region).
• Do not connect other electrical equipment to the same power
outlet to which the scanner is connected. Also, when using an
extension cord, make sure that the extension cord is rated for the
current requirements of the scanner.
• Never disassemble or modify the AC adapter, as it is dangerous.
• The power cord may become damaged if it is often stepped on or
if heavy objects are placed on it. Continued use of a damaged
power cord and AC adapter can lead to an accident, such as a
fire or electrical shock.
• Do not use the power cord while it is coiled.
• Do not pull directly on the power cord. When disconnecting the
power cord, grasp the plug and remove it from the outlet.
• Keep the area around the power cord clear of objects so that the
power cord can be disconnected easily in an emergency.
• Do not use an AC adapter other than the one provided with the
scanner. Do not use the AC adapter provided with the scanner
with other products.
• If you have any questions regarding the power supply, contact
your local authorized Canon dealer or service representative for
further information.
8
100mm
3.94"
