STEP 2
Installing the Feed Roller
Slide the document guides to the
1
left and right, and open the roller
cover.
document
guides
roller cover
Gently press on the sides of the
4
front unit to close it. It is properly
closed when you hear a click.
Fit the feed roller in the unit by
2
aligning the notch on the roller
with the shaft on the unit.
2
Close the roller cover. It is
3
properly closed when you hear a
click.
