Technical Specifications
Technical specifications

Duty cycle

50,000-count Benchtop Multimeter
(cont.)
Displaying measurement in % of a logic signal (TTL, CMOS ...)
Duty cycle θ =
Resolution
Minimum term for θ
Maximum term for T
Minimum term for T
Nominal range
Absolute error on duty cycle,
expressed in %
Additional absolute error
(slope when set to zero)
C = rate in V or en A (for 600 V rate, C = 5000)
P = slope in V/s or A/s
Protection
θ θ
T
Duty cycle
0.01 %
10 µs
0.8 s
100 µs
5 to 95 %
0.2 % ± 0.0005 / T
0.1 x C/P
600 V
AC
= T - θ
53
