INSTALLATION INSTRUCTIONS (continued)

Component Names

Panel
Control panel
I Adjustment buttons
are located on the
bottom.
I The inner side of the
cover is provided
with indications to
distinguish the
adjustment buttons.
SELECT button
MENU button
INPUT SELECT button
4
The stand is an Optional
M L
SUB-POWER
button
VOLUME button
10
12
12
10
Front
Indicating lamp
I The main power switch is located at
the back, on the lower surface.
9
Cabinet
(front frame)
Remote-control
receiver 8
9
Main power switch
9
