Position indicators
VRX models
Modular position indicator with three removable position markers (3 yellow + 2 black), adjustable ac-
cording the type of valve to be actuated.
Valve
2-way:
0° = closed
90° = open
3-way (L) :
3-way (T) :
Ex : T1
VSX models
2- position spherical indicator
Sense of window for standard mounting:
Mounting of the position indicator
(appendix p.31 mark 1) : mount the
seal ring and the indicator then the
window with the 4 screws M4.
34
0° 90°
