16 | English
Mounting and Operation
Action
Delivery Scope
Fold down handle operation
Adjusting the Handle
Connecting to the water supply
Connecting/Disconnecting high
pressure gun to lance
Connecting high pressure water supply
hose/nozzle
Disconnecting high pressure water
supply hose/nozzle
Switching On and Off
Attaching Nozzles
Adjust water jet
Connect detergent bottle
Clean nozzle
Clean the water filter
Hose into the hose holder
Storage
Gun/lance/nozzle is stored in action
Selecting Accessories
Starting
Electrical Safety
Warning! Switch off, remove plug from mains
before adjusting, cleaning or if cable is cut,
damaged or entangled.
Your machine is double insulated for safety and requires no
earth connection. The operating voltage is 230 V AC, 50 Hz
(for non-EU countries 220 V, 240 V as applicable).
For increased electrical safety use a Residual Current Device
(RCD) with a tripping current of not more than 30 mA. Always
check your RCD every time you use it.
The supply cables must be inspected for signs of damage at
regular intervals and may only be used if in perfect condition.
If the replacement of the supply cord is necessary, this has to
be done by Bosch or an authorized Bosch service agent in or-
der to avoid a safety hazard.
Only use approved extension cables.
WARNING! Inadequate extension cables can
be dangerous. Extension cable, plug and sock-
et must be of watertight construction and in-
tended for outdoor use.
Extension cords, cables, leads, reels should only be used if
they comply with EN 61242/IEC 61242 or
IEC 60884-2-7.
If you want to use an extension cable when operating your
product, only the following cable dimensions should be used:
– Nominal Conductor Area of 1.5mm
of 20m for a Cord Extension Set
F 016 L81 568 | (26.4.17)
The connections (plugs and sockets) should be kept dry and
off the ground.
Figure Page
It is recommended that this is accomplished by means of a
1 272
cord reel which keeps the socket at least 60 mm above the
ground.
2 273
Note: If an extension cable is used it must be earthed and con-
3 273
nected through the plug to the earth cable of your supply net-
4 274
work in accordance with prescribed safety regulations.
Refer to the instruction manual of the extension cord, lead,
5 274
reel manufacturer and your local wiring regulations.
If in doubt contact a qualified electrician or the nearest Bosch
6 275
Service Centre.
For products not sold in GB:
7 275
WARNING: For your safety, it is required that the plug at-
8 276
tached to the product is connected with the extension cord.
The coupling of the extension cord must be protected against
splash water, be made of rubber or coated with rubber. The
9–10 277–278
extension cord must be used with a cable strain relief.
11 279
 Products sold in GB only: Your product is fitted with a
12 280
BS 1363/A approved electric plug with internal fuse
13 280
(ASTA approved to BS 1362).
14 281
If the plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place by an
15 281
authorised customer service agent. The replacement plug
16 281
should have the same fuse rating as the original plug.
17 282
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Products sold in AUS and NZ only: Use a residual current
device (RCD) with a rated residual current of 30 mA or
less.
Operation
Starting
Attach water supply hose (not supplied) to the mains water
supply and machine.
Connect the product to the mains supply ensuring that the
mains switch is in the off position.
Open water tap.
Press the safety lock (back button on the gun handle) to re-
lease the trigger. Fully press the trigger until there is a con-
stant flow of water to clear the air from the machine and water
supply hose. Release trigger. Press the safety lock (front but-
ton on the gun handle).
Turn button on main switch. Point the power gun downwards.
Press the trigger safety lock to release the trigger. Fully press
the trigger.
Autostop function
The machine is designed to switch off the motor when the trig-
ger is released on the gun.
2
to a max. cable length
