Gladiator GEARTRACK Instructions D'installation page 10

7.
Predrill Holes
If splitting occurs, you may find it necessary to predrill and
■
countersink the screw holes near channel ends.
9.
Repeat Until Row Complete
Repeat steps 1-4 with additional panels until you reach the
■
opposite edge of the desired coverage area.
NOTE: If installing an optional trim kit, be sure to apply the
trim around any windows, doors, and outlets you encounter
along the way, as well as to the final piece of the row if
mounting against an interior corner (see "Trim Options" for
details).
8.
Drive Remaining Screws
Drive a screw in every slot at every stud location.
■
10.
Repeat Until Desired Coverage
Repeat step 5, installing each following row of wall panels
■
until the wall is finished. If the wall is wider than the
4 ft (1.22 m) panel, you will need to stagger the vertical panel
joints in each row with the seams at the wooden studs, as
shown.
NOTE: The final row of panels can be rip cut lengthwise to fit
the required height.
10
