6.7 Water Cooling Fan Unit:
The water cooling fan will be most effective to maintain the correct
temperature for a reef aquarium by evaporative cooling if the ambient
temperature around the aquarium is between 23-25°C / 73-77°F.
Place the water cooling fan unit on the rear wall of the sump close to the
right hinge bracket and tighten the screw so that the fan unit is secured
in position, do not over tighten. The 12Vdc power cable (part of the
®
MAX C lighting hood) should be connected to the socket on the back side
of the fan unit. Once connected the water cooling can be turned on and
off as required by a switch located in the timer compartment of the hood.
NOTE: Evaporative water cooling by the use of fans such as the unit
®
provided with the MAX C will increase the rate of evaporation.
When using the water cooling fan monitor the water
temperature and the water level in the rear sump.

7 Installation of optional Chiller

(not provided):
For the long-term safety and vitality of reef inhabitants Red Sea
recommends the use of chillers with all reef aquariums. Both the
®
aquarium and cabinet of the MAX
®
The MAX C cabinet has air ventilation openings both at the front and
rear to providing the free convection cooling necessary for the efficient
operation of aquarium chillers.
Use the Accessory/chiller kit to connect a pump and return pipes to a
chiller.
1. Attach approximately 30cm (4") of 17mm (3/4") flexible pipe to
the outlet of a submersible pump (the MAX
suitable for this application) and attach one of the hose barbs to the
free end of the pipe such that the hose barb is perpendicular to the
pump.
2. Lower the pump and tube assembly into the sump so that the hose
barb is facing the rear of the sump. Feed the power cable out of
the opening in the hinge bracket above the rear wall, thread the
cable through the cable channel and plug the power cable into the
designated socket on the power center.
3. Connect the required length of 17mm (¾") flexible tubing to connect
the inlet and outlet ports of the chiller to the hose barbs on the back
of the accessory pipe unit. Lock the tubes to the hose barbs with the
lock nuts.
C systems are provided "Chiller Ready".
®
C circulation pumps are
