6.6. Configuration Menu

1.
Configuration Menu
2.
Configuration Menu
press > to enter
3.
Use + / - to adjust,
> go to next item
4.
Time:
+ change
5.
Set Day and Time
Thursday
6.
Speed Selection
7.
MAX allowed speed
3450 (600-3450rpm)
8.
MIN allowed speed
600 (600-3450rpm)
9.
Prime Duration
8:00 minutes
Note: User may set the pump to prime at the maximum allowed speed for 0-15 minutes in 30 second increments.
10.
Remote Control Mode
Stand Alone
Note: See section 5.3 for more detail.
11.
Low Temp Operation
Disabled
12.
Low Temp Setting
4ºC (39.2ºF)
Note: When the pump is stopped and the ambient temperature drops below the operation temperature set point,
the pump will prime and then run at the MAX allowed speed setting for 8 hours. Low temperature operation is
active when the pump is being remotely controlled. Low temperature operation is NOT intended to protect the
Page 21 of 32
Screen
Locked
Th 1:27PM
or > skip
1:27p
rpm
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Super Pump VS Variable Speed Pump
Buttons
Used Comments
< >
Press & hold < and > buttons for several seconds to
unlock Configuration Menu
< >
Use > to enter Configuration Menu
+ -
Use + to change clock setting
< >
Use > if clock is correct
+ -
Adjust day/time setting
< >
Move to next selection, then to next menu item
+ -
Select whether to display speed in rpm (Revolutions
per Minute) or % of full speed
< >
Move to next menu item
+ -
Set maximum running speed of pump
< >
Move to next menu item
+ -
Set minimum running speed of pump
< >
Move to next menu item
+ -
Select pump prime duration
< >
Move to next menu item
+ -
Select Stand Alone or Relay Control
< >
Move to next menu item
+ -
Enable or Disable Low Temp Operation
< >
Move to next menu item
+ -
Set temperature to activate Low Temp Operation
< >
Move to next menu item
not
IS26115VSP Rev-A
