USE
Button Function
A The button only works when the door is open.
Press Briefly = Turns the Lights On/Off at maximum
intensity.
Press and hold for 2 Seconds = Turns the Courtesy
lights On/Off.
B Door Open or Closed
Press briefly(Motor Off) = performs a
Filter saturation alarm.
Door Open or Closed
Press and hold for 2 Seconds = Enables/Disables the
Activated Charcoal Filter Alarm with the Motor
turned off and no Filter Alarm triggered.
C Door Open.
Press briefly = Activates/Deactivates Delay mode,
causing automatic shutdown of the Motor and the
Lighting system from any speed with a 30' delay. It is
disabled by pressing the same button again, turning the
motor off or closing the door.
Works both with Door Closed and Open with Motor +
Lights = Off.
Press and hold for 4 Seconds = Enables/disables the
Keyboard Lock.
D Only works with the Door Open.
Press briefly = Enables/Disables the Intensive speed.
This speed is timed to run for 6 minutes. At the end of
this time the system will return to the speed set
previously.
It is disabled by pressing the same button again, turning
the motor off or closing the door.
E Only works with the Door Open = increases the
working speed.
F Only works with the Door Open = decreases the
working speed.
G Only works with the Door Open.
Press briefly = Turns the Motor On or Off
Door Open or Closed
Press and hold for 2 Seconds with Motor and Lights
Off = Enables/Disables the Remote control.
H Door Open = Closes the Door + Lights and Motor Off
Door Closed = Opens the Door + Lights and Motor
On.
Warning: If the Door remains partially open for any
reason, press the Button to complete the opening or
closing cycle.
EN
Control panel
LED button
After 100 hours in operation the Drop symbol is
Reset
of the
displayed to indicate saturation of the Metal
Grease Filters.
After 200 hours in operation the letter
indicate saturation of the Activated Charcoal filters.
Symbol C flashes twice = A.C. Filter Alarm Activated
Symbol C flashes once = A.C. Filter Alarm Deactivated
Displays the
All the LED buttons flash twice. During the Lock the
LED buttons light up in sequence.
Displays the
The number of lighted segments increases.
The number of lighted segments decreases.
LEDs turn off
LED keys flash twice = Remote control Enabled
LED keys flash once = Remote control Disabled
C
is displayed to
Clock symbol.
I symbol.
