24 | English
Intended Use
In conjunction with a dust-category M vacuum
cleaner and with firm support of the cutting
guide, the machine is intended to cut or slot
mainly mineral materials such as reinforced con-
crete, brickwork and road surfaces without the
use of water.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Two-pin spanner for clamping nut*
2 Release lock
3 Release button for the cutting unit
4 Cutting-depth scale
5 Button for depth stop adjustment
6 Depth stop
Technical Data
Wall Chaser
Article number
Rated power input
Output power
No-load speed
Max. diameter for diamond cutting discs
Mounting bore
Slot depth
Slot width
Weight according to EPTA-Procedure 01/2003
Protection class
The values given are valid for nominal voltages [U] of 230/240 V. For lower voltage and models for specific countries,
these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines
may vary.
1 609 929 K57 | (27.11.07)
7 Chaser rollers
8 Working-direction arrow
9 Spindle lock button
10 On/Off switch
11 Service indicator(GNF 35 CA)
12 Vacuum hose*
13 Vacuum connection
14 Parallel guide(GNF 20 CA)*
15 Guide bolt for parallel guide(GNF 20 CA)*
16 Grinder spindle
17 Mounting flange
18 Diamond cutting disc*
19 Spacer discs
20 Clamping nut
21 Break-out tool*
*The accessories illustrated or described are not in-
cluded as standard delivery.
GNF 20 CA
Professional
0 601 612 5..
W
W
rpm
mm
mm
mm 0 – 20
7 – 23
mm
kg
GNF 35 CA
Professional
0 601 621 7..
900 1400
520 750
9300 9300
115 150
22.2 22.2
0 – 35
7 – 39
3.4 4.7
/ II / II
